Samsung 500GB 970 EVO NVMe M.2 SSD

General Feature

Application Client PCs
Capacity 500GB (1GB=1 Billion byte by IDEMA) * Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise)
Form Factor M.2 (2280)
Interface PCIe Gen 3.0 x4, NVMe 1.3
Dimension (WxHxD) 80.15 x 22.15 x 2.38 (mm)
Weight Max 8.0 g Weight
Storage Memory Samsung V-NAND 3-bit MLC
Controller Samsung Phoenix Controller
Cache Memory Samsung 512MB Low Power DDR4 SDRAM

Description

Description

Special Feature

TRIM Support Supported
S.M.A.R.T Support Supported
GC (Garbage Collection) Auto Garbage Collection Algorithm
Encryption Support AES 256-bit Encryption (Class 0)TCG/Opal IEEE1667 (Encrypted drive)
WWN Support Not supported
Device Sleep Mode Support Yes

Performance

Sequential Read Up to 3,400 MB/s * Performance may vary based on system hardware & configuration
Sequential Write Up to 2,300 MB/s * Performance may vary based on system hardware & configuration
Random Read (4KB, QD32) Up to 370,000 IOPS * Performance may vary based on system hardware & configuration
Random Write (4KB, QD32) Up to 450,000 IOPS * Performance may vary based on system hardware & configuration
Random Read (4KB, QD1) Up to 15,000 IOPS * Performance may vary based on system hardware & configuration
Random Write (4KB, QD1) Up to 50,000 IOPS * Performance may vary based on system hardware & configuration

Environment

Average Power Consumption (system level) * Average: 5.7 W * Maximum: 10 W (Burst mode) * Actual power consumption may vary depending on system hardware & configuration
Power consumption (Idle) Max. 30 mW * Actual power consumption may vary depending on system hardware & configuration
Allowable Voltage 3.3 V ± 5 % Allowable voltage
Reliability (MTBF) 1.5 Million Hours Reliability (MTBF)
Operating Temperature 0 – 70 ℃ Operating Temperature
Shock 1,500 G & 0.5 ms (Half sine)
